    Oxygen Pilar 3-654-25 Large Pendant with Acrylic Lens 3000K Modern - Satin Copper

    Oxygen Lighting

    3-654-25

    Regular price
    Shipping calculated at checkout.
    168 In stock, ready to ship, leaves the warehouse in 3-5 days

    Oxygen Pilar 3-654-25 Large Pendant with Acrylic Lens 3000K Modern - Satin Copper

    Oxygen Lighting MPN 3-654-25

    PILAR Acrylic Pendant -3000k- Satin Copper
    SKU: 3-654-25
    UL - Damp, ADA

    This fixture is available in additional color temperatures: 2700k, 3000k, 3500k & 4000k

    Finish: Satin Copper - Matte White Acrylic Diffuser

    Weight: 6.52 lbs

    Light Source: One 5.1 Watt LED Array 90CRI 3000k

    Total Input Voltage & Wattage: 120V-277V / 7.2W

    Lumens: 399 lm

    Dimming: TRIAC and ELV dimming at 120V AC; 0-10V dimming, 100% to 1% current output

    Mounting: Unit mounts to a 4” Octagonal J-Box, 4” Square J-Box with single device mud ring/ Deep J-Box ( required to house driver ) / Fixture supplied with 10” braided cord to customize hanging height / Optional Multi-Point canopies available

    Location Rating: Damp

    Technical Documents & Files


    Specification Sheet  Revit File  Photometrics
    Attribute Value
    Category Pendant
    Finish Satin Copper
    Family Opus
    Voltage 120 V
    Number of Bulbs 1
    Bulb Type LED
    Electricity Used 5.1
    Introduction Date 04/01/2017
    Kelvin 3000
    Ship Carton Height 9.25
    Ship Carton Length 32.75
    Ship Carton Width 9.25
    Weight 6.52
    Bulb CRI 90
    Bulb Included Yes
    Cartons Per Unit 1
    Country of Origin China
    Diffuser Material Acrylic
    Energy Saving No
    Energy Star No
    ES Lamp Included No
    Freight Only No
    Location Rating Damp Rated
    Master Pack 1
    Max Wattage 5.1 W
    Parcel Yes
    Safety Rating UL Approved
    Shade Color Matte White
    Socket Type Array
